Warbird Photographs

WWII German Aircraft Photographs - Transport

Arado 232 - Page 2

Ar232 V2 Later, A-01 (VD+YA) WNr.100003 Now with Two 1,539Hp 2-Row 14-Cylinder BMW-801A/B Radial Engines & Main Landing Gear In Kneeling Position & Roller Wheels In Ground Contact & Officer's Family Getting
Photo Under Wing
[478x226] (23K)

Ar232A-10 Wekusta 5
(TC+EG) WNr.100012
with Green Frog with White Wings On Blue Shield Unit Emblem
& MG131 13mm Nose Machine Gun & Electric Powered Dorsal Turret with MG151 20mm Cannon
Flown by Oberleutnant Rudolf Schütze to Norway On July 17, 1943
Later: Crashed & Burned Near Banak, Norway On August 26, 1943 (All Crew Lost)
[710x326] (58K)

(Top)
Ar232 V1 (GH+GN) WNr.130001 with Two 1,539Hp 2-Row
14-Cylinder BMW-801A/B Radial Engines & Retracted Crawler Track For Flight Tests
& No Stamkennzeichen, Camouflage, or Armament
June 1942
(Middle)
Same As Top, But with Main Wheel Covers
(Bottom)
Ar232A-01 (VD+YA) WNr.100003 with Two 1,539Hp 2-Row
14-Cylinder BMW-801A/B Radial Engines with Camouflage
(Dropping V2 Identity)
Starting Takeoff From a Grass Strip
[407x473] (21K)

Ar232B-07 Stab-I./KG 200
ex-7./Ergänzungs.TG
& ex-14.Transportgeschwader 4 (GD+XN) vkz (G6+YY)
vkz (A3+RB) WNr.0110029
with Four 888Hp to 986Hp
BMW-Bramo323R-2 Fafnir
9-Cylinder Radial Engines
RAF AirMin #17
Captured At Eggebek,
Schleswig-Holstein,
Germany 1945
Photo At Farnborough, UK 1945
with MG131 13mm Nose Machine Gun & Dorsal Turret MG151 20mm Cannon Removed
[350x175] (42K)

Ar232 V2 Later, A-01 (VD+YA) WNr.100003
with Two 1,539Hp 2-Row
14-Cylinder BMW-801A/B
Radial Engines
Departing After Takeoff
[600x312] (38K)

Ar232 V2 Later, A-01 (VD+YA) WNr.100003
with Two 1,539Hp 2-Row
14-Cylinder BMW-801A/B
Radial Engines
Departing After Takeoff
[799x415] (89K)

Ar232 V1 (GH+GN) WNr.130001 with Two 1,539Hp 2-Row
14-Cylinder BMW-801A/B Radial Engines & Full Wing Multi-Segment (Fowler) Flaps
[303x450] (69K)

Ar232 V2 Later, A-01 (VD+YA) WNr.100003
with 1,539Hp 2-Row 14-Cylinder BMW-801A/B Radial Engines
Is The First Of A-Series
Production Aircraft of 10 Total Made
[800x465] (19K)

Ar232 V1 (GH+GN) WNr.130001 with Two 1,539Hp 2-Row 14-Cylinder BMW-801A/B Radial Engines & Retracted Crawler Track For Flight Tests & No Stamkennzeichen, Camouflage, Or Armament June 1942
[800x470] (49K)

Ar232B-09 Transportstaffel 5
Later, 14./TG 4 & Stab-I/KG 200 (GD+XP) vkz (J4+UH)
vkz (G6+UY) vkz (A3+SB) WNr.0110031 with Four 888Hp to 986Hp BMW-Bramo323R-2 Fafnir 9-Cylinder Radial Engines At Muhldorf, Germany 1945
with MG131 13mm Nose Machine Gun & Dorsal Turret MG151 20mm Cannon Removed
[478x192] (40K)

Ar232 V1 (GH+GN) WNr.130001 with Two 1,539Hp 2-Row
14-Cylinder BMW-801A/B Radial Engines & Retracted Crawler Track For Flight Tests & Main Wheel Covers & No Stamkennzeichen, Camouflage, or Armament
June 1942
[355x200] (36K)
