Warbird Photographs

WWII German Aircraft Photographs - Fighters

Dornier 335 Pfeil - Page 13

Do335 Instrument Panel & Cockpit Photos

Do335 Instrument Panel Mockup
[1123x687] (88K)

Do335A-0x Cockpit of Early Aircraft Showing Forked Control Column In Center &
Left-Side Engines, Flight Trim, Propellers, & Oxygen-Controls &
Right-Side Weapons Controls
[477x573] (91K)

Do335A-0x Cockpit of Early Aircraft Showing Forked Control Column In Center &
Left-Side Engines, Trim, Propellors, & Oxygen Controls &
Right-Side Weapons Controls
[1111x1598] (288K)

Do335A-12 Instructor's (Rear) Cockpit
[676x949] (79K)

Do335 Cockpit After Dornier Oberpfaffenhofen Factory, Bavaria, Germany Restoration In 1975
[300x231] (18K)

Do335 Miscellaneous Photos

Do335 Cockpit Ejection-Seat
[307x351] (15K)

Do335 Testing Bomb Bay Loading Mechanism Using
SC500 500Kg Bomb
[893x1257] (316K)

Do335A-0x Rear Propeller
[558x900] (27K)

Do335 Engine Photos

Do335 Supercharged 33.9 Liter 1,726Hp Inverted V-12 DB603A-1 Engine Used In V-1 to V-4 Prototypes
[900x450] (66K)

Do335 Multiple Aircraft Photos

Photo At Post-War Scrapyard
with Four Do335s
All Captured By USA At Dornier Oberpfaffenhofen Factory, Bavaria, Germany Late April to May 1945
[L→R]:
==========================
Do335 V-12 (RP+UO) WNr.230012 White 12 on Tail
A-12 Prototype [M12]
==========================
Do335 A-12 (RP+UD) WNr.240114 White 114 on Tail
==========================
Do335 A-03 Versuchsverband.ObdL (PG+VI) WNr.240103
==========================
Do335 V-15 (RP+UI) WNr.240119 White 119 On Tail (15/19)
B-1 2nd Prototype (M15) ==========================
In Front of Do335s Is
Wreckage of Me262
==============
[674x415] (34K)

Do335 Dornier Oberpfaffenhoven Factory, Bavaria, Germany Just After War with Nine Incomplete Do335 Airframes Collected Into 1 Group On the Airfield May 1945
Front Row [L→R]:
==========================
Do335 M19 WNr.240315
White 15/19 On Tail
B-3 Prototype
==========================
Do335 M11 WNr.240318
white 18/11 On Tail
==========================
Do335 A-12 WNr.240121 (RP+UL) ==========================
Do335 A-12 WNr.240123 (RP+UN)
Rear Row [L→R]:
==========================
Do335 M21 WNr.240317
White 17/21 On Tail
==========================
Do335 M18 WNr.240314
White 14/18 On Tail
==========================
Do335 B
==========
Do335 A
==========
Do335 B-6
==========
[800x532] (78K)
